SENTRY Confined Space Tripod Standard (GSE230S). A durable and dependable anchorage solution for safe confined space entry and rescue. The standard design provides increased working height and a wider footprint compared to the compact model, offering greater versatility on site. Folding legs ensure quick and simple deployment, while the robust three-pulley head delivers multiple connection options. The GSE230S supports up to two people simultaneously (max 200kg personnel) or 250kg loads, making it suitable for a broad range of confined space and work-at-height applications.
Confined Space Safety Tripod – SENTRY Standard Tripod – Confined Access Tripod Sentry – Globestock SENTRY 230 Standard Model – GSE230S
The SENTRY Confined Space Tripod Standard (GSE230S) is a robust, high-reach tripod designed for safe confined space entry and rescue. Offering a greater working height and footprint than the compact model, it remains easy to transport, set up, and store. The tripod features folding legs for quick deployment and a durable three-pulley head for hoisting and lifting. Supporting up to two people (max 200kg) and 250kg loads, the GSE230S is ideal for manholes, shafts, tanks, and utility vaults where additional clearance is required. Certified to EN 795:2012, CEN/TS 16415:2013, ISO 12100:2010, ANSI/ASSP Z359.18, CSA Z259.15-22, AS/NZS 5532, and OSHA standards, the GSE230S provides dependable anchorage for industrial and rescue operations.
Key Features & Equipment Benefits:
- Extended Reach: provides a taller working height and wider footprint, ideal for deeper or larger confined space access points
- Rapid Deployment: folding leg design enables fast assembly and positioning in demanding environments
- Multi-Pulley Head: engineered with three pulleys to accommodate hoisting, lowering, and recovery system connections
- Dual-Person Rated: safely supports up to two workers at the same time (max 200kg personnel)
- Heavy-Duty Load Capacity: handles equipment and rescue loads up to 250kg with confidence
- Strong Yet Manageable: built for durability while remaining practical for handling and transport
- Broad-Scope Use: suited to manholes, shafts, storage tanks, and utility vaults where extra clearance is needed
- Global Compliance: certified to EN, ISO, ANSI, CSA, AS/NZS, and OSHA standards for worldwide safety assurance
Technical Information:
- Item Code: GSE230S
- MWL: 2 persons (200kg) / Equipment 250kg
- Approx. Weight: 20.8 kg / 45.86 lbs
- Dimensions (Collapsed): H 1,421 mm × Min H 1,253 mm × Base 1,064 mm × Footprint 1,334 mm
- Dimensions (Extended): H 2,307 mm × Min H 2,172 mm × Base 1,755 mm × Footprint 2,015 mm
- Pulley Head: 270 × 1,527 × 180 mm
- Folding Legs: Quick deployment
- Certifications: EN 795:2012 B, CEN/TS 16415:2013, ISO 12100, ANSI Z359.18, CSA Z259.15-22, AS/NZS 5532, OSHA 1910.140 & 1926.502
| Item Code | MWL | Weight (Approx.) | Conformities |
| GSE230C | 200 kg (personnel) / 440 lbs | 18.3 kg / 40 lbs | EN 795:2012 type B CEN/TS 16415:2013 Directive 2006/42/EC ISO 12100:2010 ANSI/ASSP Z359.18-2017 Type A CSA Z259.15-22 Class A AS/NZS 5532:2013 OSHA 1910.140 OSHA 1926.502 |
| GSE230S | 250 kg (loads) / 551 lbs | 20.8 kg / 45.8 lbs | EN 795:2012 type B CEN/TS 16415:2013 Directive 2006/42/EC ISO 12100:2010 ANSI/ASSP Z359.18-2017 Type A CSA Z259.15-22 Class A AS/NZS 5532:2013 OSHA 1910.140 OSHA 1926.502 |
Folded Dimensions:
| Size | A | B | C |
| COMPACT (GSE230C) | 270 mm / 10.63″ | 1,217 mm / 47.91″ | 180 mm / 7.09″ |
| STANDARD (GSE230S) | 270 mm / 10.63″ | 1,527 mm / 60.12″ | 180 mm / 7.09″ |
Folded Dimensions:
| Size | A | B | C | D |
| COMPACT (GSE230C)* | 1,131 mm / 44.53″ | 963 mm / 37.91″ | 841 mm / 33.11″ | 1,112 mm / 43.78″ |
| COMPACT (GSE230C)** | 1,747 mm / 68.82″ | 1,579 mm / 62.24″ | 1,315 mm / 51.77″ | 1,585 mm / 62.44″ |
| STANDARD (GSE230S)* | 1,421 mm / 55.94″ | 1,253 mm / 49.33″ | 1,064 mm / 41.89″ | 1,334 mm / 52.48″ |
| STANDARD (GSE230S)** | 2,307 mm / 90.83″ | 2,172 mm / 85.43 | 1,755 mm / 69.09″ | 2,015 mm / 79.33″ |
* at lowest setting
** at tallest setting
SPECIFICATION
SENTRY Tripod Standard (GSE230S)
Maximum Working Load (MWL): 2 persons (max 200 kg / 440 lbs) / Equipment 250 kg / 551 lbs
Approx. Weight: 20.8 kg / 45.86 lbs
Assembled Dimensions
Collapsed / Lowest Setting:
-
Height: 1,421 mm / 55.94″
-
Minimum Working Height: 1,253 mm / 49.33″
-
Base Width: 1,064 mm / 41.89″
-
Footprint Width: 1,334 mm / 52.52″
Extended / Tallest Setting:
-
Height: 2,307 mm / 90.83″
-
Minimum Working Height: 2,172 mm / 85.51″
-
Base Width: 1,755 mm / 69.09″
-
Footprint Width: 2,015 mm / 79.33″
Pulley Head Dimensions: 270 × 1,527 × 180 mm / 10.63″ × 60.12″ × 7.09″
Folding Legs: Quick and easy deployment
Certifications / Standards:
EN 795:2012 Type B, CEN/TS 16415:2013, ISO 12100:2010, ANSI/ASSP Z359.18-2017 Type A, CSA Z259.15-22 Class A, AS/NZS 5532:2013, OSHA 1910.140 & 1926.502
