Daniamant ML-300 Marker Light Series - Daniamant ML-300 Marker Lights - High Intensity LEDs - 700970, 700972, 700974, 700976

The Daniamant ML-300 Marker Light Series features high-intensity LEDs powered by external 10–27 VDC and is designed for flange mounting. The standard series includes yellow and white LEDs flashing at 25 per minute with 5 Cd intensity, a fixed red LED at 5 Cd, and the ML-300 Synch Master. Light intensity, flash rate, synchronisation (master/slave), and daylight switch settings can be programmed.

The ML-300 series is suitable for marking nets, long-line fishing gear, buoys, seismic cables, anchor chains, moorings, fish farms, oil cables, and offshore installations, and allows easy servicing and repair. For synchronisation, one light can act as the main controller (Master) with the others following its signal at distances under 90–100 m. For distances of 100–450 m, a dedicated Synch Master is required, compatible with ML-100, ML-200, and ML-300 series and powered by 4.5 VDC or 10–27 VDC.

Key Features & Equipment Benefits:

• High-Intensity LEDs: Provides bright, visible marker lights for marine and offshore marking.
• External Power 10–27 VDC: Compatible with a wide range of vessel and offshore power systems.
• ML-300 Series Options: Yellow 25-flash, White 25-flash, Red fixed, and ML-300 Synch Master for flexible marking solutions.
• Easily Programmable Features: Adjust light intensity, flash rate, synchronization (Master/Slave), and daylight switch.
• Modular Construction: Easy to service and repair, reducing maintenance time.
• Applications: Suitable for marking nets, long-line fishing gear, buoys, anchor chains, seismic cables, moorings, fish farms, oil cables, and offshore installations.
• Synch Master Option: Synchronises multiple lights up to 450 m for consistent flash patterns.
• ML Marker Light Series Compatibility: Fits ML-100, ML-200, and ML-300 lights.
• NATO Stock Numbers (NSN): Yellow 15 Cd – NSN: 6220-25-120-9988; CODE “R” – NSN: 6230-25-150-9056.

Technical Information

• LED Colours: White, Yellow, Red

• Flash Rate / Intensity: 25 flashes/min (Yellow/White), fixed Red; 5 or 15 Cd

• Power: 10–27 VDC external

• Programmable: Light intensity, flash rate, Master/Slave sync, daylight switch

• Synch Master: For 100–450 m spacing; 4.5–27 VDC

• Mounting / Dimensions: Flange mount; 155 × 100 mm

• Housing / Lens: ABS / Lexan

• Waterproof: IP-68 (5 m/1 hr)

• Applications: Nets, buoys, cables, moorings, offshore installations

• NSN: Yellow 15 Cd – 6220-25-120-9988; CODE “R” – 6230-25-150-9056
• Part No: 700970: ML-300 Yellow LED 30 flash (Oc Y 2s) 15 Cd, 700972: ML-300 White LED 25 flash 5 Cd, 700974: ML-300 Yellow LED 25 flash 5 Cd, 700976: ML-300 Synch-Master 12–24 VDC
